68-2

Manufacturer :

Signal Transformer

Product Category :

Power Transformers

Factory Lead Time :

16 Weeks

Termination Style :

Solder, Quick Connect

RoHS Status :

ROHS3 Compliant

Physical Dimension :

104.8mm X 85.7mm X 87.3mm

Width :

85.7mm

Termination :

Solder

Current - Output (Max) :

Parallel 4A Series 2A

Mount :

Chassis Mount

Mounting Type :

Chassis Mount

Primary Winding(s) :

Single, Multiple Taps

Weight :

6.8lbs 3.1kg

Moisture Sensitivity Level (MSL) :

Not Applicable

Output Voltage 2 :

34V

Output Voltage 1 :

34V

Type :

Laminated Core

Primary Rating :

SINGLE 115V

Max Output Current :

2A

Power - Max :

136VA

Voltage - Isolation :

1500Vrms

Additional Feature :

THE TWO SECONDARIES HAVE CENTER TAPPED CONNECTIONS

Reach Compliance Code :

Unknown

Voltage - Primary :

105V 115V 125V

ECCN Code :

EAR99

Height Seated (Max) :

87.30mm

Max Power Dissipation :

136W

Secondary Winding(s) :

Dual

Length :

104.8mm

Center Tap :

yes

Size / Dimension :

104.80mm Lx85.70mm W

Voltage - Secondary (Full Load) :

Parallel 34V Series 68V
