536540-1
Or copy the link below:
- Mfr.Part #
- 536540-1
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- CONN HEADER FUTUREBUS 24POS PCB
- Stock
- 10,007
- In Stock ：
- 10,007
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Specialized
- PCB Thickness :
- 1.3mm
- Circuit Application :
- Signal
- Contact Material :
- Bronze
- Mount :
- Through Hole
- Option :
- GENERAL PURPOSE
- Number of Conductors :
- ONE
- Connector Type :
- Header, Male Pins
- Color :
- Natural
- Number Of PCB Rows :
- 4
- Row Spacing :
- 2 mm
- Length - Tail :
- 4.25mm
- Number of Signal Positions :
- 24
- Insulation Resistance :
- 4mOhm
- ELV :
- Non-Compliant
- Contact Current Rating :
- 5A
- Flammability Rating :
- UL94 V-0
- Housing Material :
- Polymer
- Max Voltage Rating (AC) :
- 30V
- DIN Conformance :
- No
- Length :
- 11.88mm
- Lead Free :
- Not Applicable
- Plating Thickness :
- 30μin
- Published :
- 2007
- Body Breadth :
- 0.622 inch
- Contact Style :
- SQ PIN-SKT
- Voltage - Rated AC :
- 30V
- Mating Alignment :
- With
- Reliability :
- COMMERCIAL
- Series :
- Z-PACK
- RoHS Status :
- RoHS Compliant
- PCB Mount Alignment :
- Without
- PCB Contact Pattern :
- RECTANGULAR
- Sealable :
- No
- Lifecycle Status :
- ACTIVE (Last Updated: 1 week ago)
- Filter Feature :
- No
- MIL Conformance :
- No
- Number of Positions Loaded :
- All
- Orientation :
- Vertical
- Height :
- 17mm
- Operating Supply Voltage :
- 30V
- Number of Positions :
- 24
- Number of Rows :
- 4
- Insertion Force-Max :
- .695 N
- Width :
- 16mm
- Operating Temperature :
- -55°C~125°C
- Mixed Contacts :
- No
- Packaging :
- Tube
- Material Flammability Rating :
- UL94 V-0
- Connector Style :
- Futurebus
- Polarization Key :
- POLARIZED HOUSING
- Mounting Type :
- Through Hole
- Make First / Break Last :
- yes
- Depth :
- 15.8mm
- Factory Lead Time :
- 36 Weeks
- Body/Shell Style :
- Receptacle
- Termination :
- Press-Fit
- Contact Finish :
- Gold
- Additional Feature :
- FIRST MAKE LAST BREAK
- IEC Conformance :
- No
- Pitch :
- 0.079 2.00mm
- Total Number of Contacts :
- 24
- Contact Finish Thickness - Mating :
- 760 nm
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Mating Post Length :
- 6.477mm
- Contact Pattern :
- RECTANGULAR
- Datasheets
- 536540-1
Z-PACK Series Header, Male Pins Press-Fit Gold Natural 24 Positions Pitch: 0.079 2.00mm -55°C~125°C Tube Through Hole
536540-1 Overview
A Header, Male Pins package is included with it.Its mounting type is Through Hole.Packaging is performed using a Tube case.It is part of the Z-PACK Series of products.Additionally, there are other features, such as FIRST MAKE LAST BREAK.Through Hole mounts the part.There is no operating temperature for the device.This Backplane Connector operates with a supply voltage of 30V.
