535677-5
Or copy the link below:
- Mfr.Part #
- 535677-5
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- CONN RCPT 2P 0.1 TIN-LEAD PCB RA
- Stock
- 49,840
- In Stock ：
- 49,840
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Receptacles, Female Sockets
- Pitch - Mating :
- 0.100 2.54mm
- Number of Positions :
- 2
- Contact Length - Post :
- 0.115 2.92mm
- PCB Mounting Orientation :
- RIGHT ANGLE
- Series :
- AMPMODU Mod II
- Lead Length :
- 2.92mm
- High Temperature Compatible :
- yes
- Insulation Color :
- Black
- Insulation Material :
- Polyester, Glass Filled
- Contact Type :
- Female Socket
- Number Of PCB Rows :
- 2
- Lead Free :
- Contains Lead
- Current Rating :
- 2A
- Published :
- 2008
- Termination :
- Solder
- Number of Rows :
- 1
- Connector Type :
- Receptacle
- PCB Contact Row Spacing :
- 7.874 mm
- Length :
- 5.08mm
- Option :
- GENERAL PURPOSE
- Contact Resistance :
- 12mOhm
- Number of Positions Loaded :
- All
- UL Flammability Code :
- 94V-0
- DIN Conformance :
- No
- Contact Finish Thickness - Mating :
- 100.0μin 2.54μm
- PCB Contact Pattern :
- RECTANGULAR
- Mounting Type :
- Through Hole, Right Angle
- Operating Temperature :
- -55°C~125°C
- Rated Current (Signal) :
- 2A
- Filter Feature :
- No
- Contact Finish Thickness - Post :
- 100.0μin 2.54μm
- Contact Shape :
- Square
- Housing Material :
- Polyester
- Number of Conductors :
- ONE
- Orientation :
- RIGHT ANGLE
- Contact Finish - Mating :
- Tin-Lead
- Contact Material :
- Phosphor Bronze
- Reliability :
- COMMERCIAL
- Mount :
- Through Hole
- Insulation Resistance :
- 5000000000Ohm
- Mixed Contacts :
- No
- Factory Lead Time :
- 14 Weeks
- MIL Conformance :
- No
- Insulation Height :
- 0.137 3.47mm
- Contact Plating :
- Lead, Tin
- ELV :
- Non-Compliant
- Durability :
- 75 Cycles
- Depth :
- 8.13mm
- RoHS Status :
- Non-RoHS Compliant
- Packaging :
- Tube
- Reference Standard :
- UL, CSA
- Style :
- Board to Board
- Approval Agency :
- CSA, UL
- Fastening Type :
- Push-Pull
- IEC Conformance :
- No
- Pbfree Code :
- No
- Flammability Rating :
- UL94 V-0
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Datasheets
- 535677-5
1 Rows Receptacle Solder Phosphor Bronze Through Hole, Right Angle Tube Tin-Lead Polyester, Glass Filled 2 Positions Female Socket
535677-5 Overview
Currently, it is packaged in Receptacle.The mounting type of the device is Through Hole, Right Angle.A Tube case is used to package the product.A product of the AMPMODU Mod II Series, it belongs to the range of products of that series.Through Hole represents the mounting point for the part.-55°C~125°C Operating Temperature is the default operating temperature for the device.
