407

Manufacturer :

Advanced Micro Lites

Product Category :

Rated Current (Signal) :

1A

Type :

Hair Net

Reliability :

COMMERCIAL

Body Breadth :

0.331 inch

Reach Compliance Code :

Compliant

Reference Standard :

UL

Body Depth :

0.525 inch

Factory Lead Time :

5 Weeks

DIN Conformance :

No

Wire Size (Max) :

26 AWG

Additional Feature :

3M, PANEL MOUNTABLE, POLARIZATION AVAILABLE

Pbfree Code :

yes

Mating Contact Pitch :

0.1 inch

Published :

2012

Operating Temperature (Max) :

105°C

Mating Contact Row Spacing :

0.1 inch

Mixed Contacts :

No

Total Number of Contacts :

40

Body/Shell Style :

PLUG

Contact Finish - Mating :

NOT SPECIFIED

Contact Style :

SQ PIN-SKT

Contact Design :

PREASSEM CONN

Material :

PP

Contact Pattern :

RECTANGULAR

UL Flammability Code :

94V-0

Width :

76.2mm

Operating Temperature (Min) :

-55°C

Length :

304.8m

MIL Conformance :

No

Dielectric Withstanding Voltage :

1000VAC V

Number of Rows :

2

Option :

GENERAL PURPOSE

Contact Gender :

Male

Moisture Sensitivity Level (MSL) :

Not Applicable

RoHS Status :

Non-RoHS Compliant

Filter Feature :

No

Thickness :

127μm

Insulation Resistance :

1000000000Ohm

Wire Size (Min) :

28 AWG

Color :

Black, Orange, White

Polarization Key :

POLARIZED HOUSING

IEC Conformance :

No
