354660

Share

Or copy the link below:

Mfr.Part #
354660
Manufacturer
TE Connectivity
Package / Case
Datasheet
Download
Description
DIN E 48POS F SLDR 4.5MM CL2
Stock
332
In Stock :
332

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
TE Connectivity
Product Category :
DIN 41612
Reach Compliance Code :
Compliant
Mounting Style :
Through Hole
Total Number of Contacts :
48
Insulation Resistance :
10000000000 Ω
Reliability :
COMMERCIAL
Number Of PCB Rows :
3
Mounting Option 1 :
LOCKING
PCB Contact Row Spacing :
5.08 mm
Connector Type :
BOARD EURO CONNECTOR
Number of Contacts :
48(POS)
Filter Feature :
No
MIL Conformance :
No
Terminal Length :
0.177 inch
Number of Contact Rows :
3
Mixed Contacts :
No
Subcategory :
Headers and Edge Type Connectors
Contact Gender :
FEMALE
Name of Rows Loaded :
A,C,E
Manufacturer :
ERNI
Product Length (mm) :
95(mm)
Mating Contact Row Spacing :
0.2 inch
Product Height (mm) :
11.6(mm)
Option :
GENERAL PURPOSE
HTS Code :
8536.69.40.40
Contact Material :
NOT SPECIFIED
Body Breadth :
0.618 inch
Pitch (mm) :
5.08(mm)
PCB Contact Pattern :
RECTANGULAR
Insertion Force-Max :
1.251 N
Contact Style :
SQ PIN-SKT
Durability :
400 Cycles
IEC Conformance :
No
Termination Method :
Solder
Mounting Type :
BOARD
Polarization Key :
POLARIZED HOUSING
Gender :
F
Dielectric Withstanding Voltage :
2200VAC V
Product Depth (mm) :
15.7(mm)
ECCN Code :
EAR99
Body/Shell Style :
PLUG
Termination Type :
Solder
Type :
Backplane
Additional Feature :
RoHS Compliant
Mating Contact Pitch :
0.2 inch
Terminal Pitch :
5.08 mm
Body Depth :
0.457 inch
DIN Conformance :
yes
Contact Resistance :
15 mΩ
Body Orientation :
Straight
Rated Current (Signal) :
5.5 A
Reference Standard :
UL, CSA
Introducing DIN 41612 TE Connectivity 354660 from Chip IC,where excellence meets affordability. This product stands out with its Mounting Type:BOARD, Type:Backplane, 354660 pinout, 354660 datasheet PDF, 354660 amp .Beyond DIN 41612 TE Connectivity 354660 ,we also offer 09031962921, 5535032-4, 5535090-4, Our vast inventory has you covered. Contact us now for immediate solutions.

TE Connectivity 354660


354660 datasheet pdf and Barrel - Audio Connectors product details from Erni stock available at Xinshop
