3006056
Or copy the link below:
- Mfr.Part #
- 3006056
- Manufacturer
- Phoenix Contact
- Package / Case
- Datasheet
- Download
- Description
- CONN TERM BLK FEED THRU 4-22 AWG
- Stock
- 15
- In Stock ：
- 15
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Phoenix Contact
- Product Category :
- Din Rail, Channel
- Flammability Rating :
- UL94 V-0
- Stripping Length :
- 11mm
- Wire Gauge (Min) :
- 4 AWG
- Lead Pitch :
- 12.2mm
- Voltage - Rated :
- 800V
- Voltage - Rated AC :
- 800V
- ECCN Code :
- EAR99
- HTS Code :
- 8536.69.40.40
- Length :
- 42.5mm
- Max Current Rating :
- 101A
- Factory Lead Time :
- 6 Weeks
- Color :
- Blue
- Height :
- 54mm
- RoHS Status :
- RoHS Compliant
- Safety Approval :
- UL; CSA
- Reach Compliance Code :
- Unknown
- Current - IEC :
- 76A
- Wire Gauge or Range - mm² :
- 2.5-25mm2
- Wire/Cable Gauge :
- 4 AWG
- Wire Gauge or Range - AWG :
- 4-22 AWG
- Voltage :
- 600V
- Current Rating :
- 101A
- Weight :
- 24.139987g
- Material - Insulation :
- Polyamide (PA), Nylon
- Housing Material :
- Polyamide
- Current :
- 85A
- Number of Levels :
- 1
- Mount :
- CABLE
- Depth :
- 12.2mm
- Termination Style :
- Screw
- Number of Poles :
- 2
- Pbfree Code :
- yes
- Wire Gauge (Max) :
- 22 AWG
- Max Supply Voltage :
- 800V
- Type :
- Feed Through
- Approval Agency :
- CB, CSA, KEMA, UL, cULus
- Material Flammability Rating :
- UL94 V-0
- Number of Positions :
- 2
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Width :
- 12.2mm
- Published :
- 2005
- Series :
- CLIPLINE UK
- Datasheets
- 3006056
3006056 datasheet pdf and Terminal Blocks - Din Rail, Channel product details from Phoenix Contact stock available at Xinshop
