3-644615-2
- Mfr.Part #
- 3-644615-2
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- CONN HEADER VERT 2POS 3.96MM
- Stock
- 42,294
- In Stock :
- 42,294
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Male Pins
- Insulation Material :
- Thermoplastic, Glass Filled
- Packaging :
- Bulk
- Plating Thickness :
- 150μm
- Length :
- 7.8mm
- Current Rating :
- 7A
- Connector Type :
- Header
- Feature :
- Board Guide
- Contact Resistance :
- 3mOhm
- Series :
- MTA-156
- Mixed Contacts :
- No
- Circuit Application :
- Power
- Housing Material :
- Polyester
- Orientation :
- Vertical
- Mounting Type :
- Through Hole
- Max Voltage Rating (AC) :
- 600V
- Mating Post Length :
- 11.43mm
- Contact Type :
- Male Pin
- Approval Agency :
- CSA
- MIL Conformance :
- No
- IEC Conformance :
- No
- Flammability Rating :
- UL94 V-0
- Lead Length :
- 3.18mm
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Lifecycle Status :
- ACTIVE (Last Updated: 5 days ago)
- Contact Retention :
- Without
- Mount :
- Through Hole
- Pitch - Mating :
- 0.156 3.96mm
- Contact Gender :
- Male
- Number of Rows :
- 1
- Contact Current Rating :
- 7A
- PCB Thickness :
- 1.57mm
- Contact Material :
- COPPER ALLOY
- Style :
- Board to Cable/Wire
- Housing Color :
- Natural
- Applications :
- General Purpose, Industrial
- Shrouding :
- Shrouded - 1 Wall
- Material Flammability Rating :
- UL94 V-0
- Factory Lead Time :
- 16 Weeks
- Fastening Type :
- Friction Lock
- Operating Temperature :
- -55°C~105°C
- JESD-609 Code :
- e3
- Number of Power Positions :
- 2
- HTS Code :
- 8536.69.40.40
- Current Rating (Amps) :
- Varies by WireGAuge
- Published :
- 2008
- Filter Feature :
- No
- ECCN Code :
- EAR99
- PCB Contact Pattern :
- RECTANGULAR
- Number of Positions Loaded :
- All
- Number Of PCB Rows :
- 1
- Insulation Height :
- 0.545 13.84mm
- Contact Finish - Mating :
- Tin
- Voltage - Rated AC :
- 600V
- Contact Finish Thickness - Post :
- 150.0μin 3.81μm
- Sealable :
- No
- Contact Shape :
- Square
- Polarization Key :
- POLARIZED HOUSING
- UL Flammability Code :
- 94V-0
- Voltage - Rated :
- 600VAC
- Depth :
- 10.8mm
- Contact Length - Mating :
- 0.450 11.43mm
- Reliability :
- COMMERCIAL
- ELV :
- Compliant
- Contact Finish Thickness - Mating :
- 150.0μin 3.81μm
- Overall Contact Length :
- 0.700 17.78mm
- Height :
- 13.843mm
- DIN Conformance :
- No
- Operating Supply Voltage :
- 600V
- Number of Conductors :
- ONE
- Insertion Force-Max :
- .8896 N
- Underplate Material :
- Nickel
- Insulation Resistance :
- 5000000000Ohm
- Termination :
- Solder
- Contact Length - Post :
- 0.125 3.18mm
- Terminal Pitch :
- 3.96mm
- Pbfree Code :
- yes
- RoHS Status :
- RoHS Compliant
- Datasheets
- 3-644615-2
MTA-156 Series 1-Row Header Solder Copper Alloy Bulk Through Hole Tin Thermoplastic, Glass Filled Board to Cable/Wire 0.545 13.84mm Height
3-644615-2 Overview
You get it in Header packaging.Mounting type Through Hole is selected for the device.Packaged in a Bulk case.A member of the MTA-156 Series.Here's a possible application for the device: General Purpose, Industrial.This feature renders it more powerful in a number of ways because of its Board Guide feature.There's a Through Hole mount on the part.It operates at a voltage of 600V.Device runs in -55°C~105°C operating temperature.
3-644615-2 Features
MTA-156 series
3-644615-2 Applications
There are a lot of TE Connectivity AMP Connectors
3-644615-2 Rectangular Connectors applications.
