3-1879675-3

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

Unclassified

Type :

Metal Film

Termination Style :

Axial

Package :

Box

Temperature Range @ Derated Power :

70 TO 155

Product Diameter (mm) :

2.5

Manufacturer :

TE Connectivity

Power Rating(s) :

0.25 (1/4)(W)

Pbfree Code :

yes

Product Status :

Active

Maximum Voltage Rating (V) :

350

Packing Method :

Tape

Terminal Shape :

Wire

Temperature Coefficient :

±25(ppm/°C)

Resistance :

26700(ohm)

Operating Temp Range :

-55C to 155C

Rated Power Dissipation (P) :

0.25 W

Construction :

Cylindrical

Termination Forming :

Not Formed

Series :

*

Tolerance :

0.1%

Temperature Coefficient (ppm/°C) :

±25

Flame-Proof Support :

No

Surface Mount :

No

Mounting :

Through Hole

Rated Temperature :

70 °C

Number of Terminals :

2

Working Voltage :

350 V

Lead Spacing (nom) :

Not Required(mm)

ECCN (US) :

EAR99

Failure Rate :

Not Required

Power Rating (W) :

0.25 (1/4)

Maximum Operating Temperature (°C) :

155

Product Length (mm) :

7.2

Product Weight (g) :

0.24

Resistor Type :

FIXED RESISTOR

Minimum Operating Temperature (°C) :

-55

Temperature Range @ Derated Power (°C) :

70 TO 155

Packaging :

Bandoliered

Case Style :

Conformal Coated

Tolerance (+ or -) :

0.1%

Lead Diameter (mm) :

0.6

Mounting Feature :

THROUGH HOLE MOUNT

Additional Feature :

PRECISION

Package Shape :

Cylindrical

Product Height (mm) :

Not Required(mm)

Resistance Value (Ohm) :

26.7k

ECCN Code :

EAR99

RoHS Status :

RoHS Compliant

Lead Length (mm) :

30

Fail Safe Fusible Resistor :

No

Product Depth (mm) :

Not Required(mm)

Reach Compliance Code :

Compliant

Military Standard :

Not Required
