2900303

Manufacturer :

Phoenix Contact

Product Category :

Power Relays, Over 2 Amps

Contact Material :

Silver Tin Oxide (AgSnO)

Height :

80mm

Feature :

Lighted Indicator, Socket Included

Input Current :

4.8mA

Operating Temperature :

-40°C~60°C

Depth :

6.2mm

Throw Configuration :

SPDT

Wire Gauge (Max) :

26 AWG

Current Rating :

6A

Turn On Delay Time :

5 ms

Factory Lead Time :

4 Weeks

Published :

2011

Number of Contacts :

5

Series :

PLC-RPT

Coil Current :

4.8mA

Package / Case :

Module

Relay Type :

GENERAL PURPOSE

Operate Time :

5ms

Wire Gauge (Min) :

14 AWG

Switching Voltage :

250VAC 250VDC -Max

Coil Type :

Non Latching

Mounting Type :

DIN Rail

Termination :

Screwless

Voltage - Rated DC :

250V

Mount :

DIN Rail

Contact Form :

SPDT (1 Form C)

Max Input Voltage :

60V

Coil Voltage :

60VDC

Length :

80mm

Voltage - Rated AC :

250V

RoHS Status :

RoHS Compliant

Coil Voltage (DC) :

60V

Termination Style :

Spring Terminal

Turn-Off Delay Time :

8 ms

Approval Agency :

UL

Number of Circuits :

1

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Packaging :

Bulk

Max Voltage Rating (DC) :

60V
