284051-4

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

Headers, Plugs and Sockets

Contact Material :

Phosphor Bronze

Wire Gauge or Range - AWG :

12-30 AWG

Insulation Height :

0.984 25.00mm

Wire Gauge or Range - mm² :

0.05-3mm2

Voltage - Rated :

600V

Wire Gauge (Max) :

30 AWG

Max Current Rating :

15A

Lead Free :

Not Applicable

Operating Temperature :

-40°C~110°C

Number of Decks :

1

ECCN Code :

EAR99

Safety Approval :

UL

Number of Contacts :

4

Torque - Screw :

0.79 Nm (7.0 Lb-In)

Type :

Plug, Female Sockets

Number of Levels :

1

Pitch :

0.400 10.16mm

Housing Material :

Polyamide (PA66), Nylon 6/6

Color :

Green

Packaging :

Bulk

Material Flammability Rating :

UL94 V-0

RoHS Status :

RoHS Compliant

Plug Wire Entry :

90°

Wire Gauge (Min) :

30 AWG

Termination Style :

Screw - Rising Cage Clamp

Pbfree Code :

yes

Series :

Buchanan

Current :

15A

Orientation :

Straight

Voltage :

300V

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Factory Lead Time :

19 Weeks

Lifecycle Status :

ACTIVE (Last Updated: 3 days ago)

Termination :

Screw

Number of Ways :

2

Mounting Type :

Free Hanging (In-Line)

Current Rating :

15A

Mount :

Cable, Free Hanging

Feature :

Retention Latches (Wire Side)

Radiation Hardening :

No

Flammability Rating :

UL94 V-0

Screw Size :

M3

Connector Type :

PLUG

ELV :

Compliant

Number of Rows :

1

Contact Mating Finish :

Tin

Published :

2007

Wire Strip Length :

6-7.5mm
