284047-2

Share

Or copy the link below:

Mfr.Part #
284047-2
Manufacturer
TE Connectivity AMP Connectors
Package / Case
Datasheet
Download
Description
TERM BLOCK PLUG 2POS 5.08MM
Stock
960
In Stock :
960

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
TE Connectivity AMP Connectors
Product Category :
Headers, Plugs and Sockets
Series :
Buchanan
Number of Ways :
22
Additional Feature :
PA66, 94V-0, POLARIZED, LATCHED
Plug Wire Entry :
90°
Material Flammability Rating :
UL94 V-0
Torque - Screw :
0.79 Nm (7.0 Lb-In)
Mounting Type :
Free Hanging (In-Line)
ECCN Code :
EAR99
Termination Style :
Screw - Rising Cage Clamp
Wire Gauge or Range - mm² :
0.05-3mm2
Operating Temperature :
-40°C~110°C
Number of Positions :
2
Wire Strip Length :
6-7.5mm
Number of Decks :
1
Max Voltage Rating (AC) :
300V
Feature :
Retention Latches (Wire Side)
Wire Gauge (Min) :
12 AWG
Lead Free :
Lead Free
Packaging :
Bulk
Insulation Height :
0.984 25.00mm
Current :
15A
Color :
Green
RoHS Status :
RoHS Compliant
HTS Code :
8536.69.40.40
Contact Material :
Phosphor Bronze
Flammability Rating :
UL94 V-0
Type :
Plug, Female Sockets
Number of Contacts :
2
Lifecycle Status :
ACTIVE (Last Updated: 1 day ago)
Contact Mating Finish :
Tin
Published :
2007
Safety Approval :
UL
Screw Size :
M3
Number of Rows :
1
Voltage :
300V
Pitch :
0.200 5.08mm
Mount :
Cable, Free Hanging
Voltage - Rated AC :
300V
Wire Gauge or Range - AWG :
12-30 AWG
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Factory Lead Time :
19 Weeks
Current Rating :
15A
Housing Material :
Polyamide (PA66), Nylon 6/6
Wire Gauge (Max) :
30 AWG
Number of Levels :
1
Connector Type :
PLUG
ELV :
Compliant
Voltage - Rated :
300V
Orientation :
Straight
Max Current Rating :
15A
Termination :
Screw
Radiation Hardening :
No
Datasheets
284047-2
Introducing Headers, Plugs and Sockets TE Connectivity AMP Connectors 284047-2 from Chip IC,where excellence meets affordability. This product stands out with its Mounting Type:Free Hanging (In-Line), Operating Temperature:-40°C~110°C, Type:Plug, Female Sockets, Voltage:300V, 284047-2 pinout, 284047-2 datasheet PDF, 284047-2 amp .Beyond Headers, Plugs and Sockets TE Connectivity AMP Connectors 284047-2 ,we also offer 1984028, TJ0211530000G, 1945151, Our vast inventory has you covered. Contact us now for immediate solutions.

TE Connectivity AMP Connectors 284047-2


Bulk 0.200 5.08mm Green 1 Levels Free Hanging (In-Line) Plug, Female Sockets Buchanan Polyamide (PA66), Nylon 6/6 Tin Phosphor Bronze

284047-2 Overview


This product is packaged in a Plug cartonThis device's mounting type is Free Hanging (In-Line).It's packaged in a Bulk case.Buchanan Series product.There are also features like PA66, 94V-0, POLARIZED, LATCHED, just to name a few.Its Retention Latches (Wire Side) feature makes it more powerful in a number of ways.Cable, Free Hanging is mounting the part.Running in -40°C~110°C Operating Temperature.There are a number of benefits that this part has in common with other Plug, Female Sockets products.

284047-2 Features


Buchanan series


284047-2 Applications


There are a lot of TE Connectivity AMP Connectors
284047-2 Terminal Blocks applications.


  • Datacom
  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
