2640780000
Or copy the link below:
- Mfr.Part #
- 2640780000
- Manufacturer
- Weidmuller
- Package / Case
- Datasheet
- Download
- Description
- TERM BLK PLUG 4POS 180DEG 3.5MM
- Stock
- 210
- In Stock ：
- 210
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Weidmuller
- Product Category :
- Headers, Plugs and Sockets
- Voltage - IEC :
- 320V
- Current - IEC :
- 8A
- Voltage - UL :
- 300V
- Color :
- Green
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Screw Size :
- M2
- Series :
- Omnimate CPS
- Plug Wire Entry :
- 180°
- Mounting Type :
- Free Hanging (In-Line)
- Housing Material :
- Polyamide (PA), Nylon
- Number of Positions :
- 4
- Pitch :
- 0.138 3.50mm
- Type :
- Plug, Female Sockets
- Factory Lead Time :
- 10 Weeks
- Packaging :
- Bulk
- Material Flammability Rating :
- UL94 V-0
- Wire Gauge or Range - AWG :
- 16-30 AWG
- Termination Style :
- Screw - Clamping Yoke (Tension Sleeve)
- Feature :
- Mating Flange
- Operating Temperature :
- -40°C~105°C
- Wire Strip Length :
- 6.5mm
- Contact Mating Finish :
- Tin
- Contact Material :
- COPPER ALLOY
- Number of Levels :
- 1
- Torque - Screw :
- 0.22-0.25 Nm (1.9-2.2 Lb-In)
- Wire Gauge or Range - mm² :
- 0.2-1.5mm2
- Insulation Height :
- 0.437 11.10mm
- Datasheets
- 2640780000
2640780000 Documents
Bulk 0.138 3.50mm Green 1 Levels Free Hanging (In-Line) Plug, Female Sockets Omnimate CPS Polyamide (PA), Nylon Tin Copper Alloy
2640780000 Overview
Its mounting type is Free Hanging (In-Line).Packaging is performed using a Bulk case.It is part of the Omnimate CPS Series of products.A number of features make it more powerful because of its Mating Flange feature.There is no operating temperature for the device.Several of the benefits of this part are also shared by other Plug, Female Sockets products.
2640780000 Features
Omnimate CPS series
2640780000 Applications
There are a lot of Weidmüller
2640780000 Terminal Blocks applications.
- Datacom
- Communication
- Medical technology
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
- Blowers
