2508051217Z0

Manufacturer :

Fair-Rite Products Corp.

Product Category :

Ferrite Beads and Chips

Radiation Hardening :

No

Number of Lines :

1

Factory Lead Time :

12 Weeks

Operating Temperature :

-55°C~125°C

Width :

1.25mm

DC Resistance (DCR) (Max) :

200mOhm

Tolerance :

25%

Shielding :

Unshielded

Mounting Type :

Surface Mount

Current Rating :

250mA

Height :

900μm

Packaging :

Tape and Reel (TR)

RoHS Status :

ROHS3 Compliant

DC Current :

250mA

Height (Max) :

0.043 1.10mm

Case Code (Imperial) :

0805

Resistance :

200mOhm

Length :

2mm

Max Operating Temperature :

125°C

Current Rating (Max) :

300mA

Impedance :

120Ohm

Test Frequency :

100MHz

Published :

2006

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Depth :

1.25mm

Package / Case :

0805 (2012 Metric)

Material :

Ferrite

Outside Diameter :

900 μm

Max DC Current :

250mA

Min Operating Temperature :

-55°C

Termination :

SMD/SMT

Case Code (Metric) :

2012

Military Standard :

Not

Size / Dimension :

0.079Lx0.049W 2.00mmx1.25mm

REACH SVHC :

Unknown

Filter Type :

Signal Line

Core Material :

Ferrite
