24-750-LPI
Or copy the link below:
- Mfr.Part #
- 24-750-LPI
- Manufacturer
- Signal Transformer
- Package / Case
- Datasheet
- Download
- Description
- PWR XFMR SEMI-TORO 18VA TH
- Stock
- 9,080
- In Stock ：
- 9,080
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Signal Transformer
- Product Category :
- Power Transformers
- Approval Agency :
- UL; CSA; TUV
- Max Output Current :
- 1.5A
- Factory Lead Time :
- 18 Weeks
- Height Seated (Max) :
- 30.00mm
- RoHS Status :
- ROHS3 Compliant
- Published :
- 2009
- Center Tap :
- No
- Output Power :
- 18W
- Series :
- LPI
- Number of Contacts :
- 8
- Voltage - Isolation :
- 4000Vrms
- Termination :
- PC Pin
- Current - Output (Max) :
- Parallel 1.5A Series 750mA
- Termination Style :
- PC Pin
- Number of Secondary Winding :
- 2
- Primary Winding(s) :
- Dual
- Size / Dimension :
- 66.80mm Lx55.60mm W
- Power - Max :
- 18VA
- Type :
- Semi-Toroidal
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Lead Free :
- Lead Free
- Mount :
- Through Hole
- ECCN Code :
- EAR99
- Output Voltage 1 :
- 12V
- Weight :
- 0.95lb 430.91g
- Mounting Type :
- Through Hole
- Max Power Dissipation :
- 18W
- Voltage - Secondary (Full Load) :
- Parallel 12V Series 24V
- Voltage - Primary :
- 115V 230V
- Frequency :
- 60Hz
- Width :
- 55.6mm
- Datasheets
- 24-750-LPI
24-750-LPI datasheet pdf and Power Transformers product details from Signal Transformer stock available at
