207253-1

Manufacturer :

TE Connectivity Aerospace Defense and Marine

Product Category :

D-Sub Connector Assemblies

Lifecycle Status :

ACTIVE (Last Updated: 5 days ago)

Hole Diameter :

3.9116 mm

Max Operating Temperature :

125°C

Mixed Contacts :

No

Number of Positions :

9

ELV :

Compliant

Connector Style :

D-Sub

Shell Size, Connector Layout :

1 DE E

Color :

Blue

Mounting Type :

Free Hanging (In-Line)

RoHS Status :

RoHS Compliant

Moisture Sensitivity Level (MSL) :

Not Applicable

Shell Material, Finish :

Brass, Gold Plated

Current Rating :

7.5A

Orientation :

Straight

Plating :

Gold

Contact Style :

Crimp

Contact Design :

PREASSEM CONN

Factory Lead Time :

8 Weeks

Total Number of Contacts :

9

Filter Feature :

No

MIL Conformance :

No

Option :

GENERAL PURPOSE

Flange Feature :

Housing/Shell (Unthreaded)

IEC Conformance :

No

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Sealable :

No

Packaging :

Bulk

Reliability :

COMMERCIAL

Length :

31.19mm

Number of Ports :

1

DIN Conformance :

No

Series :

AMPLIMITE 109

Connector Type :

Receptacle for Female Contacts

Dielectric Material :

Polyester

Lead Free :

Lead Free

Number of Rows :

2

Min Operating Temperature :

-55°C

Shell Finish Thickness :

50μin 1.27μm

Housing Material :

Brass

Note :

Contacts Not Included

Published :

2004

Contact Type :

Signal

Mount :

Cable, Free Hanging

Empty Shell :

No

Gender :

Receptacle
