1393315-9
Or copy the link below:
- Mfr.Part #
- 1393315-9
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- 300
- Datasheet
- Download
- Description
- RELAY AUTO SPST-NO-DM 130A 24V
- Stock
- 371
- In Stock ：
- 371
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Automotive Relays
- REACH SVHC :
- Unknown
- Width :
- 40mm
- Lifecycle Status :
- ACTIVE (Last Updated: 3 days ago)
- Must Operate Voltage :
- 14.4VDC
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Number of Pins :
- 4
- Lead Free :
- Not Applicable
- Mount :
- Chassis, Flanges, Screw
- Termination Style :
- Screw Terminal
- Throw Configuration :
- SPST
- Package / Case :
- 300
- Switching Voltage :
- 24VDC - Nom
- Packaging :
- Bulk
- Max Current Rating :
- 300A
- Coil Voltage :
- 24VDC
- Coil Current :
- 170.2mA
- Termination :
- Screw
- Coil Power :
- 4.1W
- Height :
- 45mm
- Published :
- 2009
- Factory Lead Time :
- 32 Weeks
- Contact Rating (Current) :
- 130A
- Must Release Voltage :
- 2.4VDC
- Radiation Hardening :
- No
- Depth :
- 40mm
- Contact Material :
- Silver Tin Oxide (AgSnO)
- Min Operating Temperature :
- -40°C
- Release Time :
- 8ms
- Relay Type :
- Relay
- Current Rating :
- 130A
- ELV :
- Compliant
- Coil Voltage (DC) :
- 24V
- Max Operating Temperature :
- 125°C
- Contact Form :
- SPST-NO (DM) (1 Form X)
- Operating Temperature :
- -40°C~125°C
- Number of Contacts :
- 2
- Coil Resistance :
- 141Ohms
- Operate Time :
- 25ms
- Weight :
- 220.162397g
- Series :
- HCR 150
- RoHS Status :
- RoHS Compliant
- Contact Resistance :
- 50mOhm
- Coil Type :
- Non Latching
- Length :
- 63mm
- Mounting Type :
- Chassis Mount
- Datasheets
- 1393315-9
