1393315-2
Or copy the link below:
- Mfr.Part #
- 1393315-2
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Dust Cover
- Datasheet
- Download
- Description
- RELAY AUTO SPST-NO 130A 12V
- Stock
- 146
- In Stock ：
- 146
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Automotive Relays
- Seal :
- Sealed
- Contact Current Rating :
- 130(A)
- Switching Voltage :
- 12 VDC
- Package / Case :
- Dust Cover
- Termination Style :
- Screw Terminal
- Series :
- HCR 150
- Product Height (mm) :
- 71(mm)
- Relay Construction :
- Non-Latching
- LED Indicator :
- No
- Product Type :
- Automotive Relays
- Supplier Package :
- Dust Cover
- Minimum Operating Temperature :
- -40°C
- Pin Count :
- 4
- Coil Termination :
- Connector
- Dropout Volt :
- 1.2VDC
- Terminal Type :
- Screw
- Coil Suppression Diode :
- No
- Contact Termination :
- Screw
- Minimum Dropout Voltage :
- 1.2 VDC
- Contact Form :
- 1 FORM A
- Brand :
- TE Connectivity / AMP
- Coil Resistance :
- 37 Ohm
- Switching Current :
- 300A
- Contact Arrangement :
- SPST-NO
- Depth :
- 40mm
- Height :
- 71mm
- Standards Met :
- IEC
- Coil Current :
- 324.3(mA)
- Type :
- High Current Relay
- Operate Time :
- 25 ms
- Mounting Style :
- Flange
- Rad Hardened :
- No
- Coil Power :
- 3.9W
- Coil Voltage DC :
- 12
- Subcategory :
- Relays
- Contact Configuration :
- SPST
- Contact Material :
- Silver Tin Oxide
- Mounting Type :
- Flange Mount
- Operating Temp Range :
- -40C to 125C
- Operating Temperature :
- -40 to 125 °C
- Number of Poles :
- 1
- Manufacturer :
- TE Connectivity
- Length :
- 63mm
- RoHS :
- Details
- Coil Voltage :
- 12V DC
- Mounting :
- Flange Mount
- Maximum Operating Temperature :
- +125°C
- Packaging :
- Bulk
- Product Category :
- Automotive Relays
- Application :
- Engine Controls, Glow Plugs, Heated Front Screens, Preheating Systems
- Pick-up Voltage (Max) :
- 7.2VDC
- Datasheets
- 1393315-2
