1393280-5
Or copy the link below:
- Mfr.Part #
- 1393280-5
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Package / Case
- Datasheet
- Download
- Description
- RELAY AUTO SPST-NO 30A 12V
- Stock
- 4,429
- In Stock ：
- 4,429
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Potter & Brumfield Relays
- Product Category :
- Automotive Relays
- Product Length (mm) :
- 13.2(mm)
- Contact Form :
- 1 FORM A
- Turn Off Voltage (Min) :
- 1.5 VDC
- LED Indicator :
- No
- Operating Temperature :
- -40°C ~ 105°C
- Moisture Sensitivity Level (MSL) :
- --
- Length :
- 11.9888 mm
- Contact Material :
- Silver Tin Oxide
- Product Status :
- Active
- Relay Type :
- Relay
- Termination :
- PCB
- Coil Type :
- Non Latching
- Depth :
- 12.2 mm
- Series :
- Micro Relay K
- Release Time :
- 1.5ms
- Current Rating :
- 20 A
- Mounting Style :
- Through Hole
- Max Operating Temperature :
- 105 °C
- Termination Style :
- PC Pin
- Product Depth (mm) :
- 12.2(mm)
- Must Operate Voltage :
- 6.9 VDC
- Coil Voltage (DC) :
- 12 V
- Seal :
- Unsealed
- Contact Arrangement :
- SPST-NO
- Contact Current Rating :
- 30 A
- Coil Voltage DC :
- 12
- Contact Current :
- 30A
- Number of Contacts :
- 1
- ELV :
- Compliant
- Coil Suppression Diode :
- No
- Mounting Type :
- Through Hole
- Base Product Number :
- 1393280
- Coil Power :
- 567 mW
- Height :
- 9.9 mm
- Coil Current :
- 47.24(mA)
- Weight :
- 3.997283 g
- Mount :
- Through Hole
- Turn On Voltage (Max) :
- 6.9 VDC
- Min Operating Temperature :
- -40 °C
- Switching Voltage :
- 12VDC - Nom
- RoHS :
- Compliant
- Coil Resistance :
- 254(ohm)
- Coil Voltage :
- 12VDC
- Width :
- 12.9032 mm
- Manufacturer Lifecycle Status :
- ACTIVE (Last Updated: 2 years ago)
- Packaging :
- Bulk
- Contact Configuration :
- SPST-NO, SPST-NC
- Must Release Voltage :
- 1.5 VDC
- Features :
- --
- Package :
- Tube
- Lifecycle Status :
- Production (Last Updated: 2 years ago)
- Operate Time :
- 3ms
- Relay Construction :
- Non-Latching
- Type :
- Automotive Relay
- Throw Configuration :
- SPST
- Rad Hardened :
- No
- Product Height (mm) :
- 10.1(mm)
- Contact Rating (Current) :
- 30A
- Datasheets
- 1393280-5
