114529

Manufacturer :

TE Connectivity

Product Category :

Hard Metric, Standard

Contact Material :

NOT SPECIFIED

Reliability :

COMMERCIAL

Connector Style :

AB 19

Operating Temperature :

-55°C ~ 125°C

Mounting Type :

BOARD

Additional Feature :

COMPACTPCI, STANDARD: IEC 61076-4-101

Terminal Pitch :

2 mm

Contact Gender :

FEMALE

Rated Current (Signal) :

1.5 A

Filter Feature :

No

Mixed Contacts :

No

Reach Compliance Code :

Compliant

Pbfree Code :

yes

Insulation Resistance :

10000000000 Ω

Body Depth :

0.931 inch

DIN Conformance :

No

IEC Conformance :

yes

Connector Usage :

-

HTS Code :

8536.69.40.40

Reference Standard :

UL, CSA

Number of Positions :

95

Number Of PCB Rows :

5

Contact Finish Thickness :

-

Polarization Key :

GUIDE SLOT(S)

Mating Contact Pitch :

0.079 inch

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Base Product Number :

-

Mounting Style :

RIGHT ANGLE

Termination :

Press-Fit

Body Breadth :

0.545 inch

Body/Shell Style :

PLUG

Number of Rows :

5

Mating Contact Row Spacing :

0.079 inch

Mounting Option 2 :

LOCKING

Insertion Force-Max :

.7228 N

Contact Finish :

Gold

Withdrawl Force-Min :

.139 N

Voltage Rating :

-

Contact Resistance :

20 mΩ

Pitch :

0.079 (2.00mm)

Mounting Option 1 :

LOCKING MECH

Package :

Tray

Contact Style :

SQ PIN-SKT

PCB Contact Row Spacing :

2.0066 mm

Features :

Upper Shield

Option :

GENERAL PURPOSE

Terminal Length :

0.118 inch

UL Flammability Code :

94V-0

Product Status :

Last Time Buy

Series :

-

Dielectric Withstanding Voltage :

750VAC V

Number of Positions Loaded :

All

Contact Pattern :

RECTANGULAR

ECCN Code :

EAR99

Total Number of Contacts :

95

PCB Contact Pattern :

RECTANGULAR

MIL Conformance :

No

Termination Type :

Press Fit

Connector Type :

BOARD CONNECTOR
