100-014-001
Or copy the link below:
- Mfr.Part #
- 100-014-001
- Manufacturer
- 3M
- Package / Case
- Datasheet
- Download
- Description
- CONN IC DIP SOCKET 14POS GOLD
- Stock
- 38,985
- In Stock ：
- 38,985
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- 3M
- Product Category :
- IC Sockets
- Number of Contacts :
- 14
- Width :
- 10.2mm
- Published :
- 2008
- Contact Material - Post :
- Brass
- Mount :
- Through Hole
- Number of Pins :
- 14
- Current Rating (Amps) :
- 1A
- Contact Plating :
- Gold
- Contact Finish - Post :
- Gold
- Feature :
- Closed Frame, Seal Tape
- Housing Material :
- Polyphenylene Sulfide (PPS), Glass Filled
- Operating Temperature :
- -65°C~125°C
- Pitch :
- 2.54mm
- Contact Material :
- Copper
- RoHS Status :
- Non-RoHS Compliant
- Pitch - Post :
- 0.100 2.54mm
- Contact Material - Mating :
- BERYLLIUM COPPER
- Pitch - Mating :
- 0.100 2.54mm
- Length :
- 17.8mm
- Number of Positions or Pins (Grid) :
- 14 (2 x 7)
- Height :
- 4.1mm
- Termination :
- Solder
- Mounting Type :
- Through Hole
- Contact Finish Thickness - Mating :
- 8.00μin 0.203μm
- Termination Post Length :
- 0.126 3.20mm
- Material Flammability Rating :
- UL94 V-0
- Contact Finish Thickness - Post :
- Flash
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Packaging :
- Bulk
- Series :
- 100
- Type :
- DIP, 0.3 (7.62mm) Row Spacing
- Contact Finish - Mating :
- Gold
- Datasheets
- 100-014-001
100-014-001 datasheet pdf and Sockets for ICs, Transistors product details from 3M stock available at Xinshop
