PL8200

Manufacturer :

iNRCORE

Product Category :

Common Mode Chokes

Published :

2008

Max DC Current :

14A

Height :

12.7mm

Mounting Type :

Surface Mount

Factory Lead Time :

11 Weeks

Size / Dimension :

1.220Lx1.000W 30.99mmx25.40mm

Tolerance :

35%

Depth :

25.4mm

Radiation Hardening :

No

RoHS Status :

Non-RoHS Compliant

Packaging :

Tape and Reel (TR)

Current Rating (Max) :

14A

Operating Temperature :

-55°C~130°C

Filter Type :

Power Line

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

DC Resistance (DCR) (Max) :

8mOhm

Inductance :

470 µH

Height (Max) :

0.500 12.70mm

Number of Lines :

2

Package / Case :

Horizontal, 4 PC Pad
